Skid Steer Loader HW-T360

Training on Arrival

One-year warranty

Factory Direct

Basic Specifications:

Operating Load: 300-400Kg
Bucket Capacity: 0.12cbm
Rated Power: 15-18kw

Hengwang Group aims to provide you with complete engineering equipment solutions to reduce your costs and increase your profits.

HW-T360
Host performance parameters		Overall dimensions parameters
Engine brand	Popular science/Baliton	Maximum operating height/mm	2450
Rated power/KW	13.5	to bucket pin height/mm	1870
Calibrated speed/ rpm	3000	Vehicle height	1300
Number of cylinders	1	Maximum height of bucket when lying flat/mm	1810
Displacement/cc	420	Total length without accessories	1450
Emission Standards	EUR 5	With standard bucket overall length/mm	2100
Rated load/Kg	200	Maximum height unloading angle	34°
Maximum load/Kg	300	Unloading height/mm	1510
Maximum breakout force/ KN	350	Unloading distance/mm	450
Bucket volume/m3	0.12	Bucket flip angle on the ground	27°
Driving speedkm/h	0-6	Bucket flip angle at highest position	114°
Fuel tank volume/L	5	Wheelbase/mm	720
Operating quality/Kg	900	Ground clearance/mm	150
Tire model	15*72	Bucket width/mm	1000

Excellent maneuverability: It can maneuver with agility, allowing operators to easily perform precise turns and movements.
Powerful performance: Typically equipped with high-power engines, it can handle various loads and work requirements.
Efficient and multifunctional: It can be equipped with various attachments such as buckets, forks, and blades, making it suitable for a variety of construction and engineering tasks.
