BW Series Mud Pump
Training on Arrival
One-year warranty
Factory Direct
Basic Specifications:
Max. flow: 150L/min~ 320L/min
Max. pressure: 7Mpa~10Mpa
Power: 7.5kw~30kw
Hengwang Group aims to provide you with complete engineering equipment solutions to reduce your costs and increase your profits.
BackBW Series Mud Pump:
1. BW mud pump is widely used for grouting and mud jacking in engineering construction.
2. BW mud pump have four gear shifts.Output and drilling depth are adjustable,so it can be used to grout cement slurry or equipped with drilling machine.
3. BW mud pump is widely used in railway, hydraulic engineering, metallurgical engineering, building construction, geological exploration, engineering exploration.
BW Series Mud Pump Features:
1. BW mud pump is horizontal triplex grout pump with high stability and high pressure.
2. Eight gear shift to adjust the flow, large output capacity, simple operation.
3. High quality pump parts, less wearing parts, long service life, low construction cost.
4. Fast suction-discharge speed, high pump efficiency.
5. Less noise and dust, environmental operation.
| Model | BW150 | BW160 | BW250 | BW320 |
| Max. flow | 150L/min | 160L/min | 250L/min | 320L/min |
| Max. pressure | 7Mpa | 10Mpa | 6Mpa | 8Mpa |
| Power | 7.5kw | 11kw | 15kw | 30kw |
| Inlet pipe diameter | 51mm | 51mm | 76mm | 76mm |
| Outlet pipe diameter | 32mm | 32mm | 51mm | 51mm |
| Weight | 560kg | 480kg | 760kg | 1000kg |
All products are guaranteed for 12 months!
